In today’s highly competitive electronics manufacturing environment, optimizing the soldering process is a critical factor in reducing costs and improving product quality. The JIT-SD205H Consolidate Multifunctional Soldering Machine is a comprehensive solution designed for exactly that challenge.
JIT Industrial Asia Pte Ltd supplies the JIT-SD205H high-speed 24V semi-automatic soldering machine, equipped with a dedicated 160W high-frequency CNC soldering station — engineered for precision, maximum efficiency, and 24/7 continuous operation.
What Is the JIT-SD205H?
The JIT-SD205H is a semi-automatic, multi-function soldering machine capable of handling a wide range of electronic components, including:
- Switches, resistors, terminals, and connectors
- LED lights, diodes, transistors, and aluminum-based lamp boards
- DB9/DB25 connectors, DC heads, audio heads, USB ports, and microphones
- Springs, coils, speakers, motors, potentiometers, and sensors
- Circuit boards, PCBs, and wiring harnesses
With such a broad application range, the JIT-SD205H is suitable for small-to-large electronics manufacturing workshops and factories.
The Production Challenges JIT-SD205H Solves
Before JIT-SD205H (Common Pain Points)
- Manual soldering leads to inconsistent quality and low throughput
- Weld quality depends heavily on the skill of each individual worker
- High labor costs — especially when scaling up production volume
- Solder waste caused by imprecise tin feeding
- Difficulty maintaining uniform quality standards across an entire production line
After Deploying JIT-SD205H
- Soldering process is standardized and partially automated
- Consistent, stable weld quality based on pre-set parameters
- Significant reduction in the number of direct-line operators required
- Precise tin feeding via stepper motor — minimal solder waste
- Higher output without increasing operating costs
Key Features & Technical Highlights
1. 24/7 Continuous Operation
The JIT-SD205H supports uninterrupted 24-hour operation, making it ideal for high-volume production environments with multi-shift demands.
2. 160W High-Frequency CNC Soldering Station
Output voltage: 40V / 400KHz. Temperature range: 50°C to 480°C with ±2°C stability — ensuring precise soldering while protecting temperature-sensitive components. The machine resolves the common issue of insufficient power and high standby consumption (9W) found in most market-standard soldering stations; total standby power for the entire unit is only 13W.
3. Stepper Motor Tin-Feed System (376D)
The stepper motor drive ensures consistent tin wire delivery from start to finish of the entire reel — no variation in tin length over time. Supports tin wire diameters from 0.5mm to 2.0mm (1.5mm and 2.0mm custom options available).
4. Fully Configurable Welding Parameters
Users can precisely adjust: tin discharge method, tin feed length (0–40mm), tin output speed (10 gears), tin return length (0–10mm), stroke range (0–50mm), travel speed (10 gears), soldering time, tin fill length, and welding time. Parameters are tailored to each specific product type.
5. Simple Operation — Low Learning Curve
The 4-digit, 0.5-inch green digital display controller is large and easy to read. A foot pedal triggers the welding cycle. Input numbers 1–17 on the controller provide full operational control. No advanced technical skills are required to operate this machine.
6. ESD-Safe Design
Soldering iron head to ground potential: below 2mV. Soldering iron head to ground resistance: less than 2 ohms — fully protecting sensitive electronic components from electrostatic discharge during the soldering process.
7. Energy-Efficient
Total standby power consumption of the entire machine is only 13W — significantly lower than conventional soldering stations (typically 9W standby for the station alone), reducing electricity costs in long-term production.
8. Robust Aluminum Alloy Construction
Compact footprint of 320mm x 240mm x 300mm, weight approximately 5.5kg — easy to install and reposition on any workbench.
Technical Specifications
| Specification | Value |
| Model | JIT-SD205H |
| Soldering Station Power | 160W + 50W |
| Output Voltage / Frequency | 40V / 400KHz |
| Input Voltage | 200–240V / 50Hz, Output 24V/2A |
| Temperature Range | 50°C – 480°C (selectable by mode) |
| Temperature Stability | ±2°C (still air, no load) |
| Standby Power (Full Unit) | 13W |
| Supported Tin Wire Diameter | 0.5mm – 2.0mm |
| Tin Feed Length | 0–40mm (customizable) |
| Stroke Range | 0–50mm (customizable) |
| Soldering Iron Head Resistance | < 2 Ohms to ground |
| Solder Tip Ground Potential | < 2 millivolts |
| Dimensions (L x W x H) | 320mm x 240mm x 300mm |
| Weight (excl. packaging) | ~5.5 kg |
| Housing Material | Aluminium Alloy |
| ESD Design | Yes |
| Warranty | 1 year (stepper motors, ECU controller, soldering station) |
Business Benefits
Increase Productivity
One JIT-SD205H can effectively replace 2–3 manual soldering operators while increasing throughput speed — thanks to optimized stroke and soldering time parameters.
Reduce Labor Costs
Simple foot-pedal operation allows a single supervisor to manage multiple machines simultaneously, delivering significant labor cost savings over the long term.
Improve Product Quality
Pre-set welding parameters are fixed and precisely repeated with every cycle — eliminating human error, reducing defect rates, and ensuring consistent solder joint quality across the entire production run.
Why Choose the JIT-SD205H?
The JIT-SD205H is more than just a soldering tool — it is a complete upgrade to your entire soldering workflow. Whether you operate a small workshop or a large-scale manufacturing facility, this machine delivers measurable improvements from day one.
- Wide application: compatible with 30+ component types
- Flexible configuration: 9 adjustable parameters to suit any product
- Reliable 24/7 operation: zero downtime during production shifts
- Compact and portable: easy to deploy across multiple workstations
- ESD-safe and energy-efficient: protects components and reduces running costs
- Low threshold for operation: minimal training required for new operators
Ready to Upgrade Your Production Line?
View full product details, pricing, and availability:
https://www.smt-mall.com/product/consolidate-multifunctional-soldering-machine-jit-sd205h/
