PVA FCS300-ES

Description

The FCS300-ES has many integrated features including:

• Low pressure, low volume atomized process
• 300 series stainless steel fluid body for superior material compatibility
• Micrometer flow adjustment with lock nut
• Divorced valve design prevents material contamination of the air section
• Compatible with all commercially available conformal coatings
• Wide viscosity range offers versatility for virtually any spray application

VALVE SPECIFICATIONS

Dimensions  190mm x 22mm x 22mm  (7.50” x 0.866” x 0.866”)

Weight  9.5 oz

Viscosity Range  1 cps – Paste

Operating Air Pressure  60 – 100 psi

Maximum Inlet Fluid Pressure  2500 psi

Wetted Components  Stainless Steel, Teflon®, Kalrez®

Transfer Efficiency  99%

Spray Pattern Width  0.125” – 0.5”
