CoolTherm® EP-6008 BLK/6010 Epoxy System

The CoolTherm® EP-6008 BLK/6010 Epoxy System by JIT Asia is a high-performance, two-component epoxy compound designed for potting and encapsulation. This product ensures excellent insulation, low stress, and high thermal conductivity, making it ideal for protecting densely packaged circuitry and electronic components.

With its low viscosity, this epoxy flows easily around intricate components, ensuring complete coverage while minimizing air entrapment. Its broad temperature range (-55°C to +155°C) makes it suitable for applications requiring stability in extreme conditions.

Categories: Chemicals, Thermal & EMI Materials

Description
Reviews (0)

Introduction

Key Features & Benefits

✔ Excellent Electrical Insulation – Protects components from moisture, dust, and vibrations.
✔ Low Viscosity – Self-leveling liquid that ensures easy flow around components.
✔ Low Stress – Minimal shrinkage and mechanical stress during curing.
✔ High Thermal Conductivity (0.3 W/m·K) – Efficient heat dissipation for sensitive electronics.
✔ Wide Temperature Range – Performs reliably from -55°C to +155°C.
✔ Fast & Adjustable Cure Time – Can be cured at room temperature or accelerated with heat.
✔ Strong Mechanical Properties – Hardness of 85 Shore D, ensuring durability.

Technical Specifications

Property	Details
Color	Black Liquid (Resin), Amber Liquid (Hardener)
Dynamic Viscosity	8000 cP @ 25°C (Resin), 55 cP @ 25°C (Hardener)
Number of Components	Two-Component (2K)
Hardness	85 Shore D
Cure Time	12 Hours @ 25°C, 2 Hours @ 65°C
Working Time	1 Hour @ 25°C
Thermal Conductivity	0.3 W/m·K
Dielectric Strength	17.7 kV/mm, 450 V/mil
Temperature Range	-55°C to +155°C
Shelf Life (Resin)	1 Year (Stored at 25°C, Unopened)
Shelf Life (Hardener)	2 Years (Stored at 25°C, Unopened)

Applications

This epoxy system is ideal for use in:

✅ Electronics & PCB Encapsulation – Protects circuits from environmental damage.
✅ Automotive Components – Ensures durability in high-temperature environments.
✅ Aerospace & Defense Electronics – Reliable insulation for extreme conditions.
✅ Industrial Power Systems – Provides thermal management for high-power devices.

Shelf Life & Storage Recommendations

EP-6008 BLK Resin: 1-year shelf life if stored at 25°C in an unopened container.
EP-6010 Hardener: 2-year shelf life under the same storage conditions.
Storage Tips: Keep containers tightly closed when not in use to prevent moisture and CO₂ absorption, which can affect viscosity and curing.
